   NXP Semiconductors BYC10-600 Hyperfast power diode BYC10-600 All information provided in this document is subject to legal disclaimers. ? NXP B.V. 2013. All rights reserved Product data sheet 27 May 2013 5 / 9 VF (V) 0 4 3 1 2 003aak458 10 5 15 20 IF (A) 0 (1) (2)(2) (3) Fig. 4. Forward current as a function of forward voltage 003aak459 VR (V) 0 600 400 200 10-3 10-5 10-4 10-1 10-2 1 IR (A) 10-6 (1) (2) (3) (4) (5) Fig. 5. Reverse leakage current as a function of reverse voltage; typical values 003aac562 trr time 100 % 25 % IF dlF dt IR IRM Qr Fig. 6. Reverse recovery definitions; ramp recovery 001aab912 time time VFRM VF IF VF Fig. 7. Forward recovery definitions |
